Roth Prescription
| Mandibular | 5 | 4 | 3 | 2 | 1 | 1 | 2 | 3 | 4 | 5 |
|---|---|---|---|---|---|---|---|---|---|---|
| in/out | 0.7 | 0.7 | 0.7 | 0.9 | 0.9 | 0.9 | 0.9 | 0.7 | 0.7 | 0.7 |
| Torque | -22° | -17° | -11° | -1° | -1° | -1° | -1° | -11° | -17° | -22° |
| Tip | 0° | 0° | 5 | 0° | 0° | 0° | 0° | 5 | 0 | 0 |
| Width | 3 | 3 | 3.2 | 2.8 | 2.8 | 2.8 | 2.8 | 3.2 | 3 | 3 |
| Maxillary | 5 | 4 | 3 | 2 | 1 | 1 | 2 | 3 | 4 | 5 |
|---|---|---|---|---|---|---|---|---|---|---|
| in/out | 0.7 | 0.7 | 0.7 | 1.05 | 0.7 | 0.7 | 1.05 | 0.7 | 0.7 | 0.7 |
| Torque | -7° | -7° | -2° | 8° | 12° | 12° | 8° | -2° | -7° | -7° |
| Tip | 0° | 0° | 11° | 9° | 5° | 5° | 9° | 11° | 0° | 0° |
| Width | 3 | 3 | 3.2 | 3 | 3.2 | 3.2 | 3 | 3.2 | 3 | 3 |
| Patient Kits | .018 | .022 |
|---|---|---|
| Upper/Lower 5×5 Hook on 3 | 55R-3-18-01 | 55R-3-22-01 |
| Upper/Lower 5×5 Hook on 3,4, & 5 | 55R-345-18-01 | 55R-345-22-01 |
MBT Prescription
| Mandibular | 5 | 4 | 3 | 2 | 1 | 1 | 2 | 3 | 4 | 5 |
|---|---|---|---|---|---|---|---|---|---|---|
| in/out | 0.7 | 0.7 | 0.7 | 0.9 | 0.9 | 0.9 | 0.9 | 0.7 | 0.7 | 0.7 |
| Torque | -17 | -12° | 0 | -6° | -6° | -6° | -6° | 0 | -12 | -17 |
| Tip | 2 | 2° | 3 | 0° | 0° | 0° | 0° | 3 | 2 | 2 |
| Width | 3 | 3 | 3.2 | 2.8 | 2.8 | 2.8 | 2.8 | 3.2 | 3 | 3 |
| Maxillary | 5 | 4 | 3 | 2 | 1 | 1 | 2 | 3 | 4 | 5 |
|---|---|---|---|---|---|---|---|---|---|---|
| in/out | 0.7 | 0.7 | 0.7 | 1.05 | 0.7 | 0.7 | 1.05 | 0.7 | 0.7 | 0.7 |
| Torque | -7° | -7° | 0° | 10° | 17° | 17° | 10° | 0° | -7° | -7° |
| Tip | 0° | 0° | 8° | 8° | 4° | 4° | 8° | 8° | 0° | 0° |
| Width | 3 | 3 | 3.2 | 3 | 3.2 | 3.2 | 3 | 3.2 | 3 | 3 |
| Patient Kits | .018 | .022 |
|---|---|---|
| Upper/Lower 5×5 Hook on 3 | 55M-3-18-01 | 55M-3-22-01 |
| Upper/Lower 5×5 Hook on 3,4, & 5 | 55M-345-18-01 | 55M-345-22-01 |
