Roth Prescription
| Mandibular | 5 | 4 | 3 | 2 | 1 | 1 | 2 | 3 | 4 | 5 |
|---|---|---|---|---|---|---|---|---|---|---|
| in/out | 1.2 | 1.2 | 1.2 | 1.5 | 1.5 | 1.5 | 1.5 | 1.2 | 1.2 | 1.2 |
| Torque | -22° | -17° | -11° | -1° | -1° | -1° | -1° | -11° | -17° | -22° |
| Tip | 0° | 0° | 5° | 0° | 0° | 0° | 0° | 5° | 0° | 0° |
| Width | 3.4 | 3.4 | 3.3 | 3 | 3 | 3 | 3 | 3.3 | 3.4 | 3.4 |
| Maxillary | 5 | 4 | 3 | 2 | 1 | 1 | 2 | 3 | 4 | 5 |
|---|---|---|---|---|---|---|---|---|---|---|
| in/out | 1.2 | 1.2 | 1.2 | 1.5 | 1.2 | 1.2 | 1.5 | 1.2 | 1.2 | 1.2 |
| Torque | -7° | -7° | -2° | 8° | 12° | 12° | 8° | -2° | -7° | -7° |
| Tip | 0° | 0° | 11° | 9° | 5° | 5° | 9° | 11° | 0° | 0° |
| Width | 3.4 | 3.4 | 3.5 | 3.3 | 3.5 | 3.5 | 3.3 | 3.5 | 3.4 | 3.4 |
| Patient Kits | .018 | .022 |
|---|---|---|
| Upper/Lower 5×5 Hook on 3 | 31R-3-18-01 | 31R-3-22-01 |
| Upper/Lower 5×5 Hook on 3,4, & 5 | 31R-345-18-01 | 31R-345-22-01 |
MBT Prescription
| Mandibular | 5 | 4 | 3 | 2 | 1 | 1 | 2 | 3 | 4 | 5 |
|---|---|---|---|---|---|---|---|---|---|---|
| in/out | 0.85 | 0.85 | 1.2 | 0.8 | 0.8 | 1.2 | 0.85 | 0.85 | 0.85 | 0.85 |
| Torque | -7° | -7° | -2° | 8° | 12° | 12° | 8° | -2° | -7° | -7° |
| Tip | 0° | 0° | 11° | 9° | 5° | 5° | 9° | 11° | 0° | 0° |
| Width | 3.5 | 3.5 | 3.8 | 3.2 | 3.5 | 3.5 | 3.2 | 3.8 | 3.5 | 3.5 |
| Maxillary | 5 | 4 | 3 | 2 | 1 | 1 | 2 | 3 | 4 | 5 |
|---|---|---|---|---|---|---|---|---|---|---|
| in/out | 0.85 | 0.85 | 1.2 | 0.8 | 0.8 | 1.2 | 0.85 | 0.85 | 0.85 | 0.85 |
| Torque | -7° | -7° | -2° | 8° | 12° | 12° | 8° | -2° | -7° | -7° |
| Tip | 0° | 0° | 11° | 9° | 5° | 5° | 9° | 11° | 0° | 0° |
| Width | 3.5 | 3.5 | 3.8 | 3.2 | 3.5 | 3.5 | 3.2 | 3.8 | 3.5 | 3.5 |
| Patient Kits | .018 | .022 |
|---|---|---|
| Upper/Lower 5×5 Hook on 3 | 31M-3-18-01 | 31M-3-22-01 |
| Upper/Lower 5×5 Hook on 3,4, & 5 | 31M-345-18-01 | 31M-345-22-01 |
