Roth Prescription
| Maxillary | 5 | 4 | 3 | 2 | 1 | 1 | 2 | 3 | 4 | 5 |
|---|---|---|---|---|---|---|---|---|---|---|
| In/Out | 1.28 | 1.28 | 1.27 | 1.43 | 1.03 | 1.03 | 1.43 | 1.27 | 1.28 | 1.28 |
| Torque | -7° | -7° | -2° | 8° | 11° | 11° | 8° | -2° | -7° | -7° |
| Tip | 0° | 0° | 8° | 9° | 5° | 5° | 9° | 8° | 0° | 0° |
| Width | 3.3 | 3.3 | 3.4 | 3 | 3.3 | 3.3 | 3 | 3.4 | 3.3 | 3.3 |
| Mandibular | 5 | 4 | 3 | 2 | 1 | 1 | 2 | 3 | 4 | 5 |
|---|---|---|---|---|---|---|---|---|---|---|
| In/Out | 1.4 | 1.39 | 1.11 | 1.5 | 1.5 | 1.5 | 1.5 | 1.11 | 1.39 | 1.4 |
| Torque | -21° | -17° | -11° | 0° | 0° | 0° | 0° | -11° | -17° | -21° |
| Tip | 0° | 0° | -7° | 0° | 0° | 0° | 0° | -7° | 0° | 0° |
| Width | 3.3 | 3.3 | 3.4 | 2.9 | 2.9 | 2.9 | 2.9 | 3.4 | 3.3 | 3.3 |
| Patient Kits | .018 | .022 |
|---|---|---|
| Upper/Lower 5×5 Hook on 3 | 20R-3-18-01 | 20R-3-22-01 |
| Upper/Lower 5×5 Hook on 3,4, & 5 | 20R-345-18-01 | 20R-345-22-01 |
MBT Prescription
| Maxillary | 5 | 4 | 3 | 2 | 1 | 1 | 2 | 3 | 4 | 5 |
|---|---|---|---|---|---|---|---|---|---|---|
| In/Out | 1.37 | 1.37 | 1.27 | 1.47 | 1.04 | 1.04 | 1.47 | 1.27 | 1.37 | 1.37 |
| Torque | -7° | -7° | 0° | 10° | 17° | 17° | 10° | 0° | -7° | -7° |
| Tip | 0° | 0° | 8° | 8° | 4° | 4° | 8° | 8° | 0° | 0° |
| Width | 3.3 | 3.3 | 3.4 | 3 | 3.3 | 3.3 | 3 | 3.4 | 3.3 | 3.3 |
| Mandibular | 5 | 4 | 3 | 2 | 1 | 1 | 2 | 3 | 4 | 5 |
|---|---|---|---|---|---|---|---|---|---|---|
| In/Out | 1.38 | 1.37 | 1.17 | 1.5 | 1.5 | 1.5 | 1.5 | 1.17 | 1.37 | 1.38 |
| Torque | -17° | -12° | 0° | -6° | -6° | -6° | -6° | 0° | -12° | -17° |
| Tip | 0° | 0° | 11° | 9° | 5° | 5° | 9° | 11° | 0° | 0° |
| Width | 3.3 | 3.3 | 3.4 | 2.9 | 2.9 | 2.9 | 2.9 | 3.4 | 3.3 | 3.3 |
| Patient Kits | .018 | .022 |
|---|---|---|
| Upper/Lower 5×5 Hook on 3 | 20M-3-18-01 | 20M-3-22-01 |
| Upper/Lower 5×5 Hook on 3,4, & 5 | 20M-345-18-01 | 20M-345-22-01 |
